Product Detail

Gel ( Gelled Electrolyte ) Battery Series

HXG Series, with its proprietary grid alloy and paste formulation, provides superior performance in both high cycling and floating applications. By combining the newly developed Nano Gel electrolyte with high density paste, the HXG series offers high recharge efficiency at very low charge current. The acid stratification is highly reduced by adding Nano Gel. It is suitable for off-grid photovoltaic, wind or hydro power application.

Summary
The WEIDA gelled battery uses the sealed gel technology and is designed for high reliability, maintenance-free power for renewable energy applications. Depending on the advantage gel technology, optimum grid and plate design, the WEIDA gel battery offers highest power and reliability for your equipments.

Typical Applications
UPS systems
Power plant
Commercial deep cycle applicat
Golf cars
Solar & Windsystem
Communications
Cathodic protection
Water pumping

Description

Model	Nominal Voltage (V)	Capacity (10Hr/Ah)	Dimension（mm）				Terminal		Weight ±3%(Kg)
Model	Nominal Voltage (V)	Capacity (10Hr/Ah)	Length	Width	Height	Total height	Type	Postion	Weight ±3%(Kg)
HXG6-100	6	100	194	170	205	210	F14	4	15.5
HXG6-150	6	150	260	180	245	250	F13	5	23
HXG6-180	6	180	307	169	220	225	F13	5	27
HXG6-200	6	200	321	176	226	229	F13	4	29.5
HXG6-300	6	300	295	178	345	348	F13	5	47
HXG8-180	8	180	260	182	295	298	F13	6	36.5
HXG12-26	12	26	166	175	125	125	F14	6	7.8
HXG12-33	12	33	195	130	155	166	F14	6	10
HXG12-40	12	40	197	165	170	170	F14	3	12.5
HXG12-42	12	42	197	165	170	170	F14	3	13.3
HXG12-44	12	44	197	165	170	170	F14	3	14
HXG12-50	12	50	229	138	211	214	F14	6	15.5
HXG12-50A	12	50	229	138	205	210	F14	6	15.5
HXG12-75	12	75	260	169	211	214	F14	6	22.5
HXG12-65	12	65	350	167	175	175	F14	3	20
HXG12-90	12	90	306	169	211	214	F14	6	27
HXG12-100	12	100	330	171	214	220	F14	6	29.5
HXG12-120A	12	120	409	176	225	225	F13	6	34
HXG12-120	12	120	406	173	208	238	F13	6	34
HXG12-150	12	150	485	172	240	240	F13	6	43
HXG12-160	12	160	530	207	210	213	F13	2	47.5
HXG12-180	12	180	530	207	210	213	F13	2	52.5
HXG12-200	12	200	522	238	218	221	F13	2	59.5
HXG12-250	12	250	521	269	220	223	F13	2	71
HXG12-50FT	12	50	277	106	221	221	F14	2	15.5
HXG12-75FT	12	75	562	114	189	189	F14	2	24.5
HXG12-100FT	12	100	506	110	224	239	F14	2	32
HXG12-100AFT	12	100	395	110	286	286	F14	2	32
HXG12-110FT	12	110	395	110	286	286	F14	2	33
HXG12-120FT	12	120	551	110	239	239	F13	2	36
HXG12-125FT	12	125	436	108	317	317	F13	2	38.5
HXG12-150FT	12	150	551	110	287	287	F13	2	48
HXG12-180FT	12	180	560	126	316	323	F13	2	56
HXG2-100	2	100	171	72	205	210	F13	7	5.6
HXG2-150	2	150	171	102	206	221	F13	4	8
HXG2-200	2	200	171	111	330	364	F12	7	12.8
HXG2-300	2	300	171	151	330	364	F12	7	18
HXG2-400	2	400	210	175	330	367	F12	8	25
HXG2-500	2	500	241	175	330	365	F12	8	30
HXG2-600	2	600	302	175	330	367	F12	8	36
HXG2-800	2	800	410	175	330	367	F12	9	50
HXG2-1000	2	1000	475	175	330	367	F12	9	60
HXG2-1500	2	1500	490	350	345	382	F12	10	93
HXG2-2000	2	2000	490	350	345	382	F12	11	120
HXG2-3000	2	3000	710	350	345	382	F12	11	180
